S3 Savage4 PRO

Written by
Rate this item
(8 votes)
S3 Savage4 PRO

1st AGP 4X card also with increased memory size and added second texture unit.



2 official revisions exists. S3 Savage4 PRO with 110/125MHz and S3 Savage4 PRO 143 with clocks 125/143MHz.

Palcal's cards:

(414) core: 110MHz memory: 16MB 121MHz. Creative CT6900 110/115MHz - works in AGP2x mode.

(393) InnoVision Savage4 Extreme rev.1.1
(393) InnoVision Savage4 Extreme rev.1.1
(393) InnoVision Savage4 Extreme rev.1.1

(393) InnoVision Savage4 Extreme rev.1.1
(393) InnoVision Savage4 Extreme rev.1.1
(393) InnoVision Savage4 Extreme rev.1.1

(414) Fastware AG460D ver.3.0
(414) Fastware AG460D ver.3.0
(414) Fastware AG460D ver.3.0

(414) Fastware AG460D ver.3.0
(414) Fastware AG460D ver.3.0
(414) Fastware AG460D ver.3.0

(414) Fastware AG460D ver.3.0
(414) Fastware AG460D ver.3.0
(414) Fastware AG460D ver.3.0

(427) InnoVision Savage4 Extreme rev.2.2
(427) InnoVision Savage4 Extreme rev.2.2
(427) InnoVision Savage4 Extreme rev.2.2

(427) InnoVision Savage4 Extreme rev.2.2
(427) InnoVision Savage4 Extreme rev.2.2
(427) InnoVision Savage4 Extreme rev.2.2

(427) InnoVision Savage4 Extreme rev.2.2
(427) InnoVision Savage4 Extreme rev.2.2
(427) InnoVision Savage4 Extreme rev.2.2

Creative CT6900
Creative CT6900
Creative CT6900

Creative CT6900
Creative CT6900
Creative CT6900

Creative CT6850
Creative CT6850
Creative CT6850

Creative CT6850
Creative CT6850
Creative CT6850




Zaatharen's cards:

Manli Savage4
Manli Savage4
Manli Savage4

Manli Savage4
Manli Savage4
Manli Savage4

Homemade cooler
Homemade cooler
Homemade cooler

Gainward Mirage 397L
Gainward Mirage 397L
Gainward Mirage 397L

Gainward Mirage 397L
Gainward Mirage 397L
Gainward Mirage 397L

Diamond Stealth III S540
Diamond Stealth III S540
Diamond Stealth III S540

Diamond Stealth III S540
Diamond Stealth III S540
Diamond Stealth III S540

Innovision Savage4 Extreme 16MB
Innovision Savage4 Extreme 16MB
Innovision Savage4 Extreme 16MB

Innovision Savage4 Extreme 16MB
Innovision Savage4 Extreme 16MB
Innovision Savage4 Extreme 16MB

S3 Savage4 PRO 8MB
S3 Savage4 PRO 8MB
S3 Savage4 PRO 8MB

S3 Savage4 PRO 8MB
S3 Savage4 PRO 8MB
S3 Savage4 PRO 8MB

S3 Savage4 PRO 32MB
S3 Savage4 PRO 32MB
S3 Savage4 PRO 32MB

S3 Savage4 PRO 32MB
S3 Savage4 PRO 32MB
S3 Savage4 PRO 32MB




Vlask's cards:

Diamond Stealth III S520 - 8MB 109,8MHz core (100MHz with other bios), mem 125,3MHz, works only in AGP2x mode.

Diamond Stealth III S520 HQ
Diamond Stealth III S520 HQ
Diamond Stealth III S520 HQ

Diamond Stealth III S520 HQ
Diamond Stealth III S520 HQ
Diamond Stealth III S520 HQ

Inno3D Savage 4 Extreme
Inno3D Savage 4 Extreme
Inno3D Savage 4 Extreme

Inno3D Savage 4 Extreme
Inno3D Savage 4 Extreme
Inno3D Savage 4 Extreme

Diamond Stealth III S540
Diamond Stealth III S540
Diamond Stealth III S540

Diamond Stealth III S540
Diamond Stealth III S540
Diamond Stealth III S540




Drivers:

S3 Gamma
S3 Gamma
S3 Gamma

S3 Displays
S3 Displays
S3 Displays


Additional Info

  • Made by: S3
  • Codename: 86C397
  • Bus: PCI, AGP 2x, AGP 4x
  • Memory Size: 8MB, 16MB, 32MB
  • Max Memory Size: 32MB
  • Memory Type: SDR
  • Year: 1999
  • Announce Date: Monday, 01 February 1999
  • Card Type: VGA
  • Family: Savage
  • Process tech: 250nm
  • Made in: Taiwan, Philippines
  • Owned by: Vlask, Palcal, Zaatharen
  • Outputs: 15 pin D‐sub
  • Price $: 120
  • Video Acceleration: MPEG-2 (DVD)
  • DirectX: DX6
  • OpenGL: 1.1
  • Core Clock (MHz): 125
  • Core: 128bit
  • Effective Memory Clock (MHz): 143
  • Memory Bus Width: 64bit
  • Memory Bandwidth (MB/s): 1144
  • Pixel Pipelines: 1
  • Texture Units: 2
  • Pixel Fillrate (MPixel/s): 140
  • Triangle/Vertices Rate (M/s): 8
  • Sold by: CreativeDiamondGainwardInnovisionManLi
  • Max Core Clock (MHz): 125
  • Min Core Clock (MHz): 110
  • Max Memory Clock (MHz): 143
  • Min Memory Clock (MHz): 121
  • Ramdac (MHz): 300
  • OpenGL/D3D report: Txt
  • Press info: S3
  • Wikipedia: Wiki
  • Review: AnandTech
  • Review: xbitlabs
  • Review: PC Mag
  • Info: S3
  • Info: PCTuning (czech)
